Network Design & Data Cabling

  •           Network cable designs and installation is governed by a set of standards that determine how to wire a data center, office or apartment building for data or voice communications, using Category 5(CAT 5E) or Category 6 cable(CAT 6E) and modular sockets. These standards define how to lay the cabling in a star formation, such that all outlets terminate at a central patch panel (which is normally 19 inch rack-mounted), from where it can be determined exactly how these connections will be used. Each outlet can be ‘patched’ into a data network switch (normally also rack mounted alongside), or patched into a ‘telecoms patch panel’ which forms a bridge into a private branch exchange (PBX) telephone system, thus making the connection a voice port.




  •     Quality Assurance
  •     Cost Effective Pricing/Minimal Overhead
  •     Fast Reliable Service
  •     Professionalism
  •     Building Long Lasting Relationships
  •     Bicsi Technicians on Staff
